一、 Product Introduction:

        In 2025, the AW small volume wide voltage series and high-performance AC/DC module power supply will be launched. Based on a market perspective and refining customer needs, we are now launching the AW10 BSxx series with high cost-effectiveness, low power consumption, and small size, with a maximum power of 10W. This series has advantages such as ultra small size, wide operating temperature range, and high cost-effectiveness.

       1) Ultra small size, flexible application scenarios

                The external dimensions are 45.7 * 25.4 * 21.5mm, suitable for occasions with high power requirements and small volume;

       2) Wide voltage range input

                85-305VAC/100-430VDC is suitable for global voltage requirements, and standard voltages such as 110/220/277VAC are also applicable;

       3）High reliability and comprehensive protection functions

              ① High isolation insulation withstand voltage 4000VAC/5mA;

              ② Output short circuit, overcurrent and other protection functions;

              ③ Overcurrent protection - Input 220VAC, overcurrent point ≥ 140% Io;

              ④ Engineering plastic shell, compliant with UL94V-0, resistant to high temperature and corrosion,

              ⑤ Environmentally friendly adhesive sealing for dust and moisture prevention.

        4) Wide operating temperature range, low power consumption

              ① Working temperature range: -40 ℃ to+85 ℃;

              ② -25~70 ℃ without derating;

              ③ The no-load power consumption is as low as 0.1W;

         5) Simplify peripheral circuits

              ① Simple peripherals can meet EMI CLASS B requirements;

              ② Simple peripheral can withstand surge disturbance of 2KV and group pulse disturbance of 4KV;

二、 Product application

    Widely applicable in various fields such as industrial control systems, smart homes, smart buildings, smart agriculture, household appliances, etc., especially suitable for places with high requirements for volume and EMI

Please refer to the detailed parameter list：      AW10-BSxx

三、 Product Features

         ●  Ultra wide input voltage range: 85-305VAC/100-430VDC

         ●  Operating temperature range: -40 ℃ to+85 ℃

         ●  Efficiency of over 80%

         ●  High power density

         ●  Low no-load power consumption

         ●  Output short circuit and overcurrent protection

         ●  All plastic shell, compliant with UL94V-0

         ●  Compliant with IEC62368, UL62368, EN62368 certifications
